T-SA Semi-Automatic Stretch Wrapper
The Transformer T-SA stretch wrapping machine is the industry leading semi-automatic turntable wrapper on the market. Featuring the largest turntable diameter and max capacity in class, the T-SA is perfectly suited to handle your toughest wrapping applications. Increase your productivity by switching to the Transformer stretch wrappers today.
Turntable Diameter: 71″ (Industry leading)
RPMs: 0-15 (adjustable SOFT start/stop)
Max Capacity: 5,000 lbs
Pre-Stretch: Up to 300%
Machine Specs:
Machine Dimensions: L 110.2” x W 70.87” x H 94.49”
Machine Weight: 1,543 Lbs
Max Capacity: 5,000 Lbs
Max Wrap Height: 83″
Max Wrap Diagonal: 102″
Recommended Wrap Diagonal: 90″
Turntable Diameter: 71”
Turntable Speed: 0-15 RPM (Adjustable SOFT start/stop)
Rotation Direction: Clockwise
Turntable Motor: 1.06 HP
Lifting Motor: 0.536 HP
Pre-Stretch Motor: 0.469 HP
Maximum Film: 19.69”
Roll Diameter: 500MM
Film Core Diameter: 2.953” / 75MM
Max Film Height: 20” / 508MM
Power Voltage: Single Phase, 110V, 50/60HZ, 1.5KW
Machine Features:
T-Power Pre-stretch:
Features adjustable pre-stretch up to 300%.
Pre-Stretch Rollers:
Our pre-stretch rollers will last a lifetime if maintained, they’re 100% guaranteed for 3 years.
Safety door:
With built in E-Stop, the film carriage door must be latched before the rollers will engage. Opening the film carriage door will automatically E-STOP the machine.
Photo-eyes:
Photo-eyes are enclosed for user/operator protection. Features auto height sensing that works with black and opaque films. Timer delays are used to apply and secure top sheets and may be adjusted to allow for overwrap. Dual photo-eyes are included to allow for an additional turntable.
E-STOP:
The main E-STOP button is on the control panel located on the right side of the machine.
Foot Safety:
A switch-plate E-STOP is located on the bottom of the film carriage for operator safety. The E-STOP foot safety switch-plate is easily accessible from the front and left side of the machine. A keyed ignition switch used to lock the power off is located on the main control panel.
Film Puncture Cutter:
The Puncture Cutter detaches film without using dangerous blades or hot wires. The puncture device is enclosed and engages automatically at the end of the wrap cycle. It retracts automatically for operator safety.
Carriage Limit Switches:
All parts are available for immediate shipment in the U.S.A. 2 year all parts warranty.
Control Panel:
Panasonic PLC
Schneider Drives
Top & Bottom Wrap With Counter:
0-99
Reinforcing Wraps Overwrap
For Top Sheets Turntable Speed:
0-16 RPM
Auto Home Positioning
Adjustable Carriage Speed (Up and Down)
Programable Cycle Counter
Film Tension
Adjustable Pre-Stretch:
0-300%
Touchscreen With Diagnostics
Programable Save And Store Settings
